MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-

MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived







Description of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

MOXA EDS-518A-SS-SC-T

EDS-518A Series
Managed Gigabit Ethernet switch with 14 10/100BaseT(X) ports, 2 100BaseFX single-mode ports with SC

connectors, and 2 combo 10/100/1000BaseT(X) or 1000BaseSFP slots for adding SFP-1G series Gigabit

Ethernet modules, -40 to 75°C operating temperature

Mfr. Part#: EDS-518A-SS-SC-T



Specification of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Input/Output Interface of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Alarm Contact Channels
Resistive load: 1 A @ 24 VDC
Digital Inputs
+13 to +30 V for state 1
-30 to +3 V for state 0
Max. input current: 8 mA


Ethernet Interface of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

10/100BaseT(X) Ports (RJ45 connector) 14
                                      Auto negotiation speed
                                      Full/Half duplex mode
                                      Auto MDI/MDI-X connection
100BaseFX Ports (single-mode SC connector) 2
Combo Ports (10/100/1000BaseT(X) or 1000BaseSFP)  2
Optical Fiber


Standards of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseSX/LX/LHX/ZX
IEEE 802.1X for authentication
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1s for Multiple Spanning Tree Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.3x for flow control
IEEE 802.3ad for Port Trunk with LACP



Ethernet Software Features of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Filter 802.1Q VLAN, Port-based VLAN, IGMP v1/v2, GVRP, GMRP
Industrial Protocols EtherNet/IP, Modbus TCP
Management IPv4/IPv6, SNMPv1/v2c/v3, LLDP, Port Mirror, Back Pressure Flow Control, BOOTP, DDM, DHCP

Option 66/67/82, DHCP Server/Client, Flow control, RARP, RMON, SMTP, SNMP Inform, Syslog, Telnet,

TFTP
MIB MIB-II, Bridge MIB, Ethernet-like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, RMON MIB Groups 1, 2, 3, 9,

RSTP MIB
Redundancy Protocols STP, MSTP, RSTP, LACP, Link Aggregation, Turbo Chain, Turbo Ring v1/v2
Security HTTPS/SSL, TACACS+, Port Lock, RADIUS, SSH, Broadcast storm protection
Time Management NTP Server/Client, SNTP



Switch Properties of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

IGMP Groups  256
MAC Table Size 8 K
Max. No. of VLANs 64
Packet Buffer Size 2 Mbits
Priority Queues 4
VLAN ID Range VID 1 to 4094


LED Interface of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

LED Indicators  PWR1, PWR2, FAULT, 10/100M (TP port), 100M (fiber port),1000M (Gigabit port), MSTR/HEAD, CPLR/TAIL


Serial Interface of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Console Port  RS-232 (TxD, RxD, GND), 8-pin RJ45 (115200, n, 8, 1)



DIP Switch Configuration of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Ethernet Interface  Turbo Ring, Master, Coupler, Reserve



Power Parameters of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Connection  2 removable 6-contact terminal block(s)
Input Current
0.52 A @ 24 VDC
Input Voltage 24 VDC, Redundant dual inputs
Operating Voltage 12 to 45 VDC
Overload Current Protection Supported
Reverse Polarity Protection Supported


Physical Characteristics of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Housing Metal
IP Rating IP30
Dimensions 94 x 135 x 142.7 mm (3.7 x 5.31 x 5.62 in)
Weight 1630 g (3.60 lb)
Installation DIN-rail mounting, Wall mounting (with optional kit)


Environmental Limits of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Operating Temperature -40 to 75°C (-40 to 167°F)
Storage Temperature (package included) -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity 5 to 95% (non-condensing)



Standards and Certifications of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Safety  EN 60950-1, UL 60950-1, CSA C22.2 No. 60950-1, UL 508
Hazardous Locations  ATEX, Class I Division 2
EMC  EN 55032/24
EMI   CISPR 32, FCC Part 15B Class A
EMS   IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
      IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
      IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
      IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
      IEC 61000-4-6 CS: 10 V
      IEC 61000-4-8 PFMF
Maritime DNV-GL, NK
Shock IEC 60068-2-27
Vibration IEC 60068-2-6
Freefall IEC 60068-2-31


MTBF of MOXA EDS-518A-SS-SC-T Managed Gigabit Ethernet Switches EDS-518A-SS-SC-T Arrived

Time 250,966 hrs
Standards  Telcordia (Bellcore), GB
Warranty
Warranty Period  5 years
